Another mobile type concrete batching plant series which comes with proven reversible drum type concrete mixer which is highly appreciated by the industry. Economic design and very cost effective than other mobile type concrete batching plants as it has very low operating cost and less connected power hence consumes less electricity.
- Load out belt conveyor
- prefeb cabin for control panel
| Model | RMB 15 | RMB 20 | RMB 30 |
|---|---|---|---|
| Output Capacity | 15 M3/Hr. | 20 M3/Hr. | 25 M3/Hr. |
| MIXER TYPE | REVERSIBLE DRUM TYPE MIXER | ||
| MAXING AND DISCHARGE OF CONCRETE | FORWARD ROTATION OF THE DRUM MIX THE MATERIAL AND REVERSE ROTATION OF THE DRUM DISCHARGE THE CONCRETE | ||
| MAIN DRIVE OF MIXER | 10HP | 15 HP | 20 HP |
| PLANT ESSEMBLY | WHOLE PLANT ESSEMBLY ON SINGLE CHASSIS | ||
| MATERIAL STORAGE SYSTEM | 2X2 CROSS BIN FEEDER | ||
| MATERIAL STORAGE CAPACITY | 10 M | 12 M | 14 M |
| MATERIAL WEIGHING SYSTEM | Digital load cell based weighing | ||
| CEMENT FEEDING SYSTEM | THROUGH INCLINED SCREW CONVEYOR | ||
| WATER FEEDING SYSYTEM | FLOW METER BASED WATER FEEDING SYSTEM | ||
| WATER TANK CAPACITY | 200 LITERS | 250 LITER | 300 LITER |
| ADMIXTURE DOZING SYSTEM | AUTO ADMIXTURE DOZING SYSTEM | ||
| TYRES | 4 NO | 4 NO | 4 NO |
| TOW BAR FACILITY | YES | YES | YES |
| CONTROL PANEL | PLC BASED CONTROL PANEL WITH INTERNAL CABLING | ||
| TOTAL CONNECTED POWER | 28 HP | 35 HP | 43 HP |
| SUGGESTED DG SET | 42 KVA | 50 KVA | 62 KVA |
| CONCRETE DISCHARGE HEIGHT | 1.2 METER | 1.5 METER | 1.8 METER |
We are a well reckoned business organization, which manufactures, supplies and exports hydraulic concrete mixer. Designed to perfection under the guidance of adept professionals, these mixers possess compact design and are ensued for their hassle free working. Further, we checkConcrete Mixer Machine on strict parameters to gauge its seamless finish and unmatched design.
- Concrete Mixer with Mechanical Hopper
- Concrete Mixer without Hopper
- Portable Hydraulic Concrete Mixer
- Digital Weight Hydraulic Concrete Mixer
| Make | KI |
|---|---|
| Cap | 10/7 Cft. |
| Type | hydraulic concrete mixer |
| Power | 10 Hp Kirloskar Engine./ 10 HP Motor Kirloskar / Crompton |
| Tyre | 5"x19" |
| Drum Thickness | |
| Bottom | 10 MM |
| Middle | 8 MM |
| Top | 6 mm |
We manufacture an extensive range of Concrete Mixer Machine With Lift, which is well known in the market for its smooth operation. We use high quality raw material that is quality tested to ensure its process . This machine is specially designed for large scale concrete mixing. This machine is manufactured with heavy duty chassis . This machine is specially designed with lift mechanism for best results. We provide 10HP engine in this machine. The specifications of these machines are as follows:
- One bag capacity
- Concrete mixing with 45ft, 55ft, 65ft lift & more..
We are engaged in offering our customers, a comprehensive range of technologically advanced Concrete Mixer Machine. Known in the market for their high study construction and high performance, thereby proving to be highly cost effective for our customers. The machine features a large diameter drum with specially shaped mixing blades, which ensures a superior mix, either dry or wet. These machines save a lot of time as the mix is prepared in a short duration. Designed to withstand continuous rough use, the drum is made by heavy gauge sheet for increasing strength. This machine is designed for small scale concrete mixing purpose. We provide 3 HP 3 PHASE motor in this machine. This machine is for fixed Purpose. Tires are not provided with this machine. The machines are currently available in one bag capacity.
